The following is a list of books and other published items relevant to the Master 512. None of these items are now in print, and they never will be again, though some of them do turn up second-hand from time to time. Several have been made available on-line, though – click on the appropriate link.

Items Specifically for the Master 512

Master 512 User Guide – Produced by Acorn and distributed with the machine. It concentrates principally on GEM, and includes very little about the DOS-Plus operating system. This makes it a very frustrating document for the majority of users, most of whom would be using DOS-Plus rather than GEM. However it is still an essential. Most owners of the 512 should have a copy of this. (PDF, scanned by Eelco Huininga)
Key Correspondence Chart and Function Key Strip for GEM Write – provided with the machine, but easily mislaid so included here.
Master 512 : Technical Information and Monitor Documentation – Covers the software in the 80186 co-processor ROM, ie the 80186 Monitor and the protocols for using the host MOS from the 512. This was produced by Acorn as a leaflet separate from the User Guide. In practice, the information is duplicated in Chapter 14 of Watford's Advanced Reference Manual for the BBC Master.
EdBin and Move User Guide – These two utilities were included in Vn 2.1 of DOS-Plus. They did not form part of the earlier release (Vn 1.2) of DOS-Plus, and are not mentioned in the main User Guide. Acorn produced this booklet to cover them. It is now extremely rare and hard to get hold of.
Master 512 User Guide by Chris Snee, published by Dabs Press. (Not to be confused with Acorn's manual of the same title – see above.) This explains how to use the machine and describes the use of DOS-Plus in some detail. Although out of print it does sometimes appear on the second-hand market, and is well worth trying to get hold of.

Master 512 Technical Guide by Robin Burton, published by Dabs Press. Takes up from where Chris Snee's book leaves off, and covers a lot of the more advanced features of the machine. Again, second-hand copies may turn up. (Note that the OCR of the disassembly listings in two of the appendices has not worked well. For this reason I have made scanned forms of Appendix E and Appendix F available as PDFs. A text form of Appendix F is also now available (with thanks to Stephen Bass).

A Programs Disc was also produced by Dabs Press to go with the Technical Guide.
512 Forum – A series of articles in Beebug magazine by Robin Burton, largely in response to readers' questions and comments (hence the name).
Other Beebug Items – There were a few articles in Beebug (other than the 512 Forum) that were relevant to the machine
Applications Compatibility and Software List – Note produced by Acorn describing some compatibility issues, and listing a number of programs believed to be compatible with the Master 512.
Circuit Diagram for the 80186 co-processor board. (Supplied, courtesy of Acorn, to accompany the Master 512 Technical Guide.)

Other Items Directly Relevant to the Master 512

80186 Data Sheet – The more technically minded might like to look at the details of the processor at the heart of the Master 512.

Appropriate Items on the BBC Computer Host

Advanced Reference Manual for the BBC Master from Watford Electronics. Chapter 12 (on Dual Processor Systems in general) and Chapter 14 (on the 80186 co-processor) are particularly relevant to the Master 512. (Chapter 14 more-or-less duplicates the content of the Technical Information and Monitor Documentation leaflet.

Note: This download contains a picture of the cover (as an RTF file), plus the contents on an image of a 640kb (large) ADFS floppy disk.
The New Advanced User Guide for BBC Master, Compact, B, B+ & Electron by Adrian Dickens & Mark Holmes. Chapter 18 gives a full summary of all the Tube protocols from the host side, and indicates what must be handled by the co-processor, though with no explicit reference to the 80186.
Tube Application Note – Official technical manual from Acorn on how the Tube should be used (PDF).

Note that many documents and other items relevant to the BBC Computer are available on-line by clicking here.
